TS 5000 L-E-ISM VPK
TS 5000 L-E-ISM VPK Overhead door closer system with guide rail, for opposite hinge side, for double leaf doors with anti-panic function, closing sequence control and electrical hold-open device
- Supply voltage 24 V DC
- Retention force of the electromechanical hold-open device can be variably adjusted
- Height compensation of +/- 2 mm possible
- Closing sequence control holds the active leaf in the waiting position until the passive leaf is closed
Application Areas
- Double leaf doors with closing sequence control
- Hold-open systems with integrated hold-open device
- Installation on the opposite hinge side
- Right and left single-action doors
- Symmetrical and asymmetrical division of door possible
Technical data
| TS 5000 L-E-ISM VPK | |
| Leaf width (max.) | 1400 mm |
| Identical design for DIN left and DIN right | Yes |
| Input voltage | 24 V DC |
| Electrical power consumption | 4.8 W |
| Duty rating | 100 % |
| Residual ripple | 20 % |
| IP rating | IP43 |
| Minimum hinge clearance | 1300 mm |
| Minimum passive leaf width | 380 mm |
| Standard conformity | EN 1154:1996/A1:2002/AC:2006, EN 1155, EN 1158 |
| Length | 2730 mm |
| Width | 55 mm |
| Height | 30 mm |
| opening restrictor upgradable | Yes |
| Hold-open device on the active leaf / passive leaf | Yes / Yes |
| Hold-open device can be overridden | Yes |
| Hold-open range | 80 ° |
| Closing sequence control integrated | Yes |
| Height correction possible | Yes |
| Flexible opening restrictor | Yes |
Downloads
Door closer TS 5000 L-ISM VPK
