TSA 355 Manual door
TSA 355 Manual door Manual revolving door system for three- or four-leaf doors
- Customised choice of diameter, passage height and surfaces
- Extensive equipment options
- Simple installation of the door system without lifting tools
- Fast commissioning thanks to pre-cabled and configured sensors
Note: The product listed may not be available in your country. Please contact your GEZE contact person or send us an e-mail.
Application Areas
- Three- and four-leaf door systems
- Interior and exterior doors with high access frequency
- Representative building entrances with large incidence of light
- Façades with slim mullion-transom constructions
- Diameters from 1740 to 3540 mm possible
Technical data
| TSA 355 Manual door | |
| Manual operation | Yes |
| With speed limiter (optional) | Yes |
| Break-out function (BO) | Yes |
| Inner diameter (min.) | 1740 mm |
| Inner diameter (max.) | 3540 mm |
| For 3-leaf door systems | Yes |
| For 4-leaf door systems | Yes |
| Clear passage height | 3000 mm |
| Canopy height (min.) | 200 mm |
| Side elements version | 8 mm LSG |
| Version of roof structure | optical sheet metal covering, waterproof roof with waterspout |
| Illumination | with roof variant, according to customer wishes |
| Floor covering | Entrance mat, Entrance mat, according to the customer’s request |
| Hot-air curtain system | hot water air curtain, Electric air curtain, possible, depends on the ceiling construction |
| Night-time closer layout | Outside |
| Night-time closer type | Manual |
| Night-time closer design | 8 mm LSG |
| Lock | Manual |
| Door handles horizontal or vertical | Yes |
| Floor ring | Yes |
