Corner fittings and pivot bearing
PT 20 Top side-hung leaf corner fitting with mount for pivot bearing bolts (ø 15 mm)
- Elegant cover caps made of polished or brushed stainless steel
- Problem-free adjustment to glass thicknesses of 10 – 12 mm
Top side-hung leaf corner fitting with mount for pivot bearing bolts (ø 15 mm)
Application Areas
- For full-glass doors
- For glass thicknesses 10 and 12 mm
- Door leaf weights up to 100 kg, door leaf widths up to 1,000 mm, door leaf heights up to 2,800 mm
- For single-action and double-action doors
- For internal and external systems
- Suitable for single and double leaf swing doors
Technical data
PT 20 | |
Type of installation | Glass installation |
Length | 163 mm |
Width | 32 mm |
Height | 51 mm |
Min. Glass thickness | 10 mm |
Max. Glass thickness | 12 mm |
