GC Lock Control SHEV
DC converter DC-to-DC converter from 24 V to 12 V, for the use of 12 V motor locks on the SHEV air inlet door
- Connection of 12 V motor lock controls or motor locks with integrated control unit
- Converts the 24 V input current to 12 V at the output
The DC-DC converter converts the 24 V input voltage from the SHEV control panel to a low output voltage in the case of fire. This allows for the use of 12 V motor locks on a SHEV air inlet door
Application Areas
- Can be used in combination with the GC Lock Control SHEV
- Top hat rail mounting
Technical data
| DC converter | |
| Type of installation | Top hat rail mounting |
| Cable dimensions (max.) | 2.5 mm² |
| Output current (max.) | 1.25 A |
| Service temperature | -40 - 85 °C |
| IP rating | IP20 |
| protection rating | III |
